AMGC41, Split Flow Hydraulic Manifold with Gauges and Frame, For Single-Acting Cylinders
Item ID: AMGC41
$3,532.83
Free ShippingEst. Ship date is Tue, NovĀ 3rd 2026
Product Specifications
Product TypeSplit Flow Manifold Assembly
Weight (kg)10,6
Weight (lbs)23.8
Available - Backorder
About this Product
Features
- Offers ease of portability and convenience with an ergonomic robust design, ready for use.
- Enerpac's CR400 female couplers on all ports allow the manifold to be quickly connected to up to 4 cylinders.
- 4 x Glycerine filled, 10,000 psi (700 bar) gauges allow operators to work safely.
- Protected by a robust protection frame.
Units:
Product TypeSplit Flow Manifold Assembly
Weight (kg)10,6
Weight (lbs)23.8
Number of Inlet Ports1
rentalPrice104
Number of Regulated Outlet Ports4
Maximum Operating Pressure (psi)10000
Maximum Operating Pressure (bar)700
Number of Outlet Ports4
Cylinder CompatibilitySingle-Acting Cylinders
Units:
