BLS1006, 105 ton Capacity, 6.34 in Stroke, Climbing Jack
Item ID: BLS1006
$12,376.12
Free ShippingEst. Ship date is Tue, Jan 19th 2027
Product Specifications
Maximum Operating Pressure (psi)10000
Cylinder Effective Area Retract (in2)9.64
Weight (lbs)695
Available - Backorder
About this Product
Features
- Climbing Jacks include integral tilt saddles with maximum tilt angles up to 5°
- Large base with anti-rotation rod for stability and safety
- Built-in safety valve prevents accidental over-pressurization
- Baked enamel finish for increased corrosion resistance
- CR-400 couplers included on all cylinder models
Units:
Maximum Operating Pressure (psi)10000
Stroke (inch)6.34
Return TypeDouble-Acting, Hydraulic Return
Plunger TypeSolid
MaterialSteel
Cylinder Effective Area Advance (in2)20.66
Cylinder Effective Area Retract (in2)9.64
Oil Capacity Advance (in3)136.57
Oil Capacity Retract (in3)63.77
Weight (lbs)695
80%
Think Safety
Manufacturer's rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
