ETT200, 225 Ton Turntable
Item ID: ETT200
Contact for Pricing
Product Specifications
Capacity (Metric Tons)225
Maximum Operating Pressure (psi)10000
Dimension L (mm)2000
About this Product
Features
- Safe and controlled rotation of heavy loads
- Easily change rotation direction
- Capacity: 225 tons with one cylinder
- Compact size for use in applications with limited space
- Compatible with standard Enerpac pumps
- Hardwood surface.
- Cylinder model number: BRD259-ETT
Units:
Capacity (Metric Tons)225
Maximum Operating Pressure (psi)10000
Dimension L (mm)2000
Platform Diameter (in)70.47
Cylinder Oil Capacity, Advance (in3)48.31
Product TypeIndustrial-Turntable
Dimension W (in)78.74
Cylinder Oil Capacity, Advance (cm3)792
Cylinder Capacity (kN)222
Dimension L (in)78.74
Maximum Operating Pressure (bar)700
Dimension W (mm)2000
Weight (kg)1700
Cylinder Oil Capacity, Retract (cm3)344
Rotation per Stroke (degrees)12,5
Weight (lbs)3748
Capacity (Imperial tons)2000
Platform Diameter (mm)1790
Number of Cylinders1
Cylinder Oil Capacity, Retract (in3)21
Cylinder Capacity (imperial ton)25
Units:
Dimension H5.91"
