FA1TMSTD, 1.1 Ton, Mechanical Flange Alignment Tool Set
Item ID: FA1TMSTD
$1,580.52
Free ShippingEst. Ship date is Mon, Oct 19th 2026
Product Specifications
Maximum Reaction Force (kN)10
Minimum Bolt Size (in)0.63
Case Dimensions (mm)180 x 330 x 220
Available - In Stock
About this Product
Features
- The FA1TM Mechanical Flange Alignment Tool is a simple solution to smaller diameter lower pressure flange joint misalignment.
- The FA1TMSTD Set includes:
1 x FA1TM Tool
1 x Mini Ratchet Strap
1 x Instruction Manual
Units:
Maximum Reaction Force (kN)10
Minimum Bolt Size (in)0.63
Case Dimensions (mm)180 x 330 x 220
Case Dimensions (in)7.1 x 13.0 x 8.7
Weight (kg)2,3
Product TypeFlange Alignment Tool
Maximum Reaction Force (imperial ton)1.1
Maximum Reaction Force (metric ton)1
Reaction Force 2 Max (imperial ton)1.1
Misalignment Min M (mm)0
Bolt Hole Diameter B Min (mm)16
Weight (lbs)5.07
Reaction Force 2 Max (metric ton)1
Minimum Bolt Size (mm)16
Bolt Hole Diameter Min (in)0.63
