FA4TMSTD, 4.5 Ton, Mechanical Flange Alignment Tool Set
Item ID: FA4TMSTD
$5,083.18
Free ShippingEst. Ship date is Mon, Oct 19th 2026
Product Specifications
rentalPrice80
Bolt Hole Diameter Min (in)1
Weight (kg)8.6
Available - In Stock
About this Product
Features
- The FA4TM Mechanical Linear & Rotational Alignment Tool is a simple solution to medium diameter, medium pressure flange joint misalignment.
- The FA4TMSTD Set includes:
1 x FA4TM Tool
1 x 68N·m (50ft·lb) Torque Wrench
1 x 22mm Socket
1 x Ratchet Strap
1 x Instruction Manual
1 x Carry-Case
Units:
rentalPrice80
Bolt Hole Diameter Min (in)1
Weight (kg)8.6
Case Dimensions (mm)600 x 370 x 200
Weight (lbs)19
Maximum Reaction Force (kN)40
Minimum Bolt Size (mm)25
Case Dimensions (in)23.6 x 14.6 x 7.9
Misalignment Min M (mm)0
Maximum Reaction Force (metric ton)4
Minimum Bolt Size (in)1
Maximum Reaction Force (imperial ton)4.5
Reaction Force 2 Max (metric ton)4
Bolt Hole Diameter B Min (mm)25
Product TypeFlange Alignment Tool
Reaction Force 2 Max (imperial ton)4.5
Capacity (Imperial tons)4
