FA9TESTD, 10.1 Ton, Hydraulic Flange Alignment Tool Set with Cylinder and Hand Pump
Item ID: FA9TESTD
$8,805.29
Free ShippingEst. Ship date is Mon, Oct 19th 2026
Product Specifications
Maximum Reaction Force (metric ton)9
Weight (lbs)32
Reaction Force 2 Max (metric ton)9
Available - In Stock
About this Product
Features
- The FA9TE Hydraulic Linear & Rotational Flange Alignment Tool is a simple solution to large diameter high pressure flange joint misalignment.
- The FA9TESTD Set includes:
1 x FA9TE Tool including Hydraulic Cylinder
1 x 10,000 psi (700 bar) Hydraulic Hose, 2m (78.75â€)
1 x 10,000 psi (700 bar) HP350S Sealed Hand Pump with Gauge
1 x Instruction Manual
1 x Carry-Case
1 x Ratchet & Strap
Units:
Maximum Reaction Force (metric ton)9
Weight (lbs)32
Reaction Force 2 Max (metric ton)9
Product TypeFlange Alignment Tool
Maximum Reaction Force (imperial ton)10.1
Bolt Hole Diameter Min (in)1.4
Maximum Reaction Force (kN)90
Minimum Bolt Size (mm)35,5
Case Dimensions (in)36.2 x 20.5 x 8.3
Minimum Bolt Size (in)1.4
Case Dimensions (mm)920 x 520 x 210
Maximum Operating Pressure (psi)10000
Misalignment Min M (mm)0
Reaction Force 2 Max (imperial ton)10.1
Maximum Operating Pressure (bar)690
rentalPrice140
Weight (kg)14.5
Bolt Hole Diameter B Min (mm)35,5
Capacity (Imperial tons)9
