FSC14, 14 Ton, Integral Hydraulic Wedge Spreader, Integrated Hand Pump, 3.16 in Maximum Spread
Item ID: FSC14
Product Description
The FSC14 Flange Spreader with its integral pump offers a convenient solution capable of exerting up to 14 tons of force (112 kN). The all-in-one design eliminates the need for a separate pump and a trailing hydraulic hose - ideal for safer working in difficult spaces at remote locations.
These flange maintenance tools fit into very small clearance gaps of 0.24 inch (6 mm). They use a friction-free, smooth, parallel wedge movement to prevent flange damage and spreading arm failure.
Product Specifications
About this Product
The FSC14 Flange Spreader with its integral pump offers a convenient solution capable of exerting up to 14 tons of force (112 kN). The all-in-one design eliminates the need for a separate pump and a trailing hydraulic hose - ideal for safer working in difficult spaces at remote locations.
These flange maintenance tools fit into very small clearance gaps of 0.24 inch (6 mm). They use a friction-free, smooth, parallel wedge movement to prevent flange damage and spreading arm failure.
Features
- Integrated wedge concept: friction-free, smooth, parallel wedge movement eliminates flange damage and spreading arm failure
- Unique interlocking wedge design: no first step bending and risk of slipping out of joint
- Requires very small access gap of only 0.24 inch (6 mm)
- Stepped spreader arm design: each step can spread under full load
- Few moving parts means durability and low maintenance
- Safety block SB1 and single-acting cylinder included
