HPT1500, Two Speed, High Pressure Hydraulic Hand Pump with Gauge, 21,750 psi
Item ID: HPT1500
Product Description
The HPT1500 is a manually operated high-pressure hydraulic tensioner pump in a convenient portable format. With no need for trailing power cords or air hoses, the HPT1500 is ideal for bolt tensioning applications where there is no power source available.
This high-pressure hand pump creates a maximum working pressure of 21,750 psi (1500 bar), and the robust, but lightweight construction provides greater portability than powered tensioner pumps.
To minimize cycle times, the two-speed operation displaces a large volume of oil per stroke at the first stage, and the included pressure gauge keeps you fully informed throughout the process.
Important: These pumps operate at ultra high-pressure, use only the specified fittings and hoses designed for these pressures.
Product Specifications
About this Product
The HPT1500 is a manually operated high-pressure hydraulic tensioner pump in a convenient portable format. With no need for trailing power cords or air hoses, the HPT1500 is ideal for bolt tensioning applications where there is no power source available.
This high-pressure hand pump creates a maximum working pressure of 21,750 psi (1500 bar), and the robust, but lightweight construction provides greater portability than powered tensioner pumps.
To minimize cycle times, the two-speed operation displaces a large volume of oil per stroke at the first stage, and the included pressure gauge keeps you fully informed throughout the process.
Important: These pumps operate at ultra high-pressure, use only the specified fittings and hoses designed for these pressures.
Features
- The Enerpac HPT high-pressure Hand Pump is ideally suited for use with hydraulic bolt tensioning tools and hydraulic nuts
- Lightweight and portable high-pressure hand pump
- Two-speed operation displaces a larger volume of oil per stroke, reducing cycle times for many testing applications
- Includes a gauge and coupler for direct connection to GT-Series bolting tools
- Integrated relief valve set at 21,750 psi
- These products operate at ultra-high pressure, use only the specified fittings and hoses designed for these pressures
