LL500, HBB Header Beam Lifting Anchor, 550 ton capacity
Item ID: LL500
Contact for Pricing
Product Specifications
Weight (lbs)485
Lug Depth F (mm)40
Beam Hole Depth B (in)43.31
About this Product
Features
- Designed to transfer the load to the top of the header beam
- Can accommodate a shackle or attach directly to the lifted load
- Used to attach rigging to header beam
- Manually spaced to desired location
Units:
Weight (lbs)485
Lug Depth F (mm)40
Beam Hole Depth B (in)43.31
Beam Hole Depth B (mm)1100
Beam Hole Width C (mm)490
Product TypeLifting Lug
Beam Hole Width C (in)19.29
Anchor Depth F (in)1.57
Gantry Series CompatibilitySL, SBL
Weight (kg)220
Anchor Width D (in)27.95
Capacity per Anchor (imperial tons)140
Pin Hole E (in)8.07
Lug Height A (mm)1955
Pin Hole E (mm)205
Lug Width D (mm)710
Gantry CompatibilityAll SL and SBL
Capacity per Anchor (kN)1250
Anchor Height A (in)76.97
