MG7TMSTD, 7.6 Ton, Mini-Gap Flange Spreader Set, 1.06 in Maximum Spread
Item ID: MG7TMSTD
$1,551.33
Free ShippingEst. Ship date is Mon, May 17th 2027
Product Description
For use on smaller, lower pressure flange joints with a minimum access gap of 2.0mm (0.08"). The tool will provide 7.6 imperial tons (68kN) of spreading force. It is recommended that tools are used in pairs giving: 15.2 imperial tons (136 kN) spreading force.
Product Specifications
Tip Clearance (mm)2
Weight (lbs)12.13
Capacity (kn)68
Available - Backorder
About this Product
For use on smaller, lower pressure flange joints with a minimum access gap of 2.0mm (0.08"). The tool will provide 7.6 imperial tons (68kN) of spreading force. It is recommended that tools are used in pairs giving: 15.2 imperial tons (136 kN) spreading force.
Features
- Features
- Reversible leg design giving greater range of applications
- Unique double angled wedge produces great spreading force without reducing spreading distance
- Robust lightweight tool
- Locks on to flange joint
- The MG7TMSTD Set Includes
- 1 x MG7TM Tool
- 2 x Spreading Bar
- Gross Set Weight: 12.13 lbs (5,5 kg)
Units:
Tip Clearance (mm)2
Weight (lbs)12.13
Capacity (kn)68
Tip Clearance (in)0.08
Capacity (Metric Tons)6.8
Maximum Spread (mm)27
Case Dimensions (in)14.2 x 11.8 x 3.5
Power SourceMechanical
Maximum Spread (in)1.06
Product TypeFlange Spreader Set - Mini-gap
Capacity (Imperial tons)7.6
Weight (kg)5,5
Case Dimensions (mm)360 x 300 x 90
