PL20014ASA, 200 Ton, 14.0 in Stroke, Pow'R-LOCK Self-Locking Portable Lifting Jack
Item ID: PL20014ASA
Contact for Pricing
Product Specifications
Handle Up Height (mm)1626
Outside Diameter B (mm)864
Capacity (Imperial tons)200
About this Product
Features
- The Pow’R-LOCK™ Lift System provides continuous positive locking of the load through all stages of lifting and lowering. No operator intervention is required to activate or deactivate the automatic locking system
- Provides continuous locking protection during lift, lower and hold functions
- Patent-pending control technology synchronizes cylinder and lock nut for smooth and efficient lifting and lowering
- Unique double-acting cylinder offers a low collapsed height to accomodate more lifting applications
- Simple 2-button pendant allows operation of raise and lower functions from up to 20 feet away
- All exposed load-bearing steel cylinder components utilize a nitrocarburizing treatment to reduce wear and resist corrosion
- Ergonomic handle has six positions for comfortable handling and folds when not in use
- Meets ANSI /ASME B30.1-2015, AS/NZS-2538, AS/NZS-2693 certification criteria
- All Pow'R-LOCK™ Lift System models feature a Tilt Load Cap to reduce side-loading
- Enerpac declares that this product has been tested and conforms to applicable standards and is approved to carry the CE mark. An EU Declaration of Conformity is enclosed separately.
- Minimum dynamic air pressure of 55-60 psi, 90-100 psi required to achieve 200 ton capacity
- Safety First - When lifting large, heavy vehicles certain precautions must be followed. Follow your published safety directions for lifting and cribbing your loads. The Pow'R-LOCK™ Lift System provides load/lock protection, but you must follow the safety directions for load cribbing operations.
Units:
Handle Up Height (mm)1626
Outside Diameter B (mm)864
Capacity (Imperial tons)200
Extended Height A (in)48
Maximum Operating Pressure (bar)700
Weight (kg)501
Saddle Diameter (in)5
Collapsed Height B (mm)864
Weight (lbs)1105
Product TypePow'R-LOCK Jack Pneumatic
Stroke (inch)14
Maximum Additional Stack Height Using Optional Extension System (mm)712
Cylinder Lifting Speed with Load (in/min)2
Front Base Width (mm)599
Front Base Width (in)23.6
Rear Wheel Width (in)25.4
Extended Height A (mm)1219
Rear Wheel Width (mm)645
Cylinder Lifting Speed NoteDepending on available airflow, regulator setting, pump speed and load weight
Maximum Operating Pressure (psi)10000
Power Source SpecAir Pump (130-150 cfm, 55-100 psi)
Stroke (mm)356
Power SourceAir
Outside Diameter (in)14.5
Handle Width (in)15.7
Outside Diameter (mm)368
Handle Height (mm)1626
Total Length (mm)2283
Jack Capacity Advance (imperial tons)200
Maximum Additional Stack Height Using Optional Extension System (in)28
Handle Down Height (mm)980
Capacity (kn)1779
Handle Down Height (in)38.6
Cylinder Lifting Speed with Load (mm/min)51
Collapsed Height (in)34
Handle Up Height (in)64
Cylinder Lifting Speed with No Load (in/min)2.4
Saddle Diameter (mm)127
Collapsed Height B (in)34
Total Length (in)89.9
Cylinder Lifting Speed with No Load (mm/min)61
Collapsed Height (mm)864
Handle Width (mm)399
