SG25TESTD, 28.1 ton, Hydraulic Secure-Grip In-Line Flange Spreader Set, 4.72 in Maximum Spread
Item ID: SG25TESTD
$13,406.32
Free ShippingEst. Ship date is Mon, Oct 19th 2026
Product Specifications
Tip Clearance (mm)0
Dimension A2, Minimum Axial Tool Space (installed) (in)43.3
Dimension R, Minimum Radial Space (mm)55
Available - In Stock
About this Product
Features
- The SG25TE In-Line secure grip bolt-hole spreader can be used on all flange types with bolt-hole sizes ranging from 2.95" (75 mm) to 4.25" (108 mm). This high-end, hydraulic model offers up to 28.1 imperial tons (250 kN) of spreading force.
- Spreading force of 56.2 imperial tons (500 kN) if used in pairs as recommended.
- Set Includes:
1 x SG25TE Tool c/w Hydraulic Cylinder
1 x Spreading plug
1 x 10,000 psi (700 bar) HP550S Sealed Hand Pump with Gauge
1 x 10,000 psi (700 bar) Hydraulic Hose, 78.7" (2 m)
1 x 12" (300 mm) Vernier Calliper
1 x Spacer Plate
1 x Safety Block
1 x Instruction Manual
1 x Carry Case with protective foam inserts - Collets sold separately
Units:
Tip Clearance (mm)0
Dimension A2, Minimum Axial Tool Space (installed) (in)43.3
Dimension R, Minimum Radial Space (mm)55
Product TypeFlange Spreader Set - Secure-Grip
Dimension V, Minimum Valve/Spacer Thickness (in)0
Dimension P2, Minimum Axial Plug Space (installed) (mm)380
Maximum Spread (in)4.72
Capacity (Metric Tons)25
Weight (lbs)110.2
Maximum Operating Pressure (bar)690
Usable on Flanges Specified to Accept the Following Bolt SizesM76 (3"), M80 (3 1/4"), M84 (3 3/8"), M90 (3 1/2"), M95 (3 3/4"), M100 (4")
Dimension A1, Minimum Axial Tool Space (for installation) (mm)750
Maximum Operating Pressure (psi)10000
Dimension P1, Minimum Axial Plug Space (for installation) (mm)380
Dimension A1, Minimum Axial Tool Space (for installation) (in)29.5
Weight (kg)50
Case Dimensions (in)35.0 x 22.4 x 6.5
Power SourceHydraulic
Dimension F, Minimum Flange Joint Thickness (mm)210
Case Dimensions (mm)890 x 570 x 165
Dimension F, Maximum Flange Joint Thickness (mm)570
Capacity (kn)250
Tip Clearance (in)0
Dimension P1, Minimum Axial Plug Space (for installation) (in)15
Maximum Spread (mm)120
Dimension F, Minimum Flange Joint Thickness (in)8.3
Dimension A2, Minimum Axial Tool Space (installed) (mm)1100
Dimension F, Maximum Flange Joint Thickness (in)22.4
Dimension P2, Minimum Axial Plug Space (installed) (in)15
Capacity (Imperial tons)28.1
Dimension V, Minimum Valve/Spacer Thickness (mm)0
Dimension R, Minimum Radial Space (in)2.2
