SWI1214TMSTDSPB, 15.7 Ton, Mechanical Flange Spreader Set, 4.1 in Maximum Spread
Item ID: SWI1214TMSTDSPB
$4,042.11
Free ShippingEst. Ship date is Mon, Oct 19th 2026
Product Description
The Equalizer SWI1214TMSTDSPB Mechanical Flange Spreader is a simple manually operated design that does not need an external hydraulic pump and hose. This makes it a great choice for working in difficult spaces at remote locations.
The spreader in the SWi1214TMSTDEX set fits into very small clearance gaps of 0.24 inch (6 mm).
Product Specifications
Case Dimensions (in)22.8 x 13.0 x 6.5
Spreader Set TypeStandard Set
Maximum Operating Torque (Nm)175
Available - In Stock
About this Product
The Equalizer SWI1214TMSTDSPB Mechanical Flange Spreader is a simple manually operated design that does not need an external hydraulic pump and hose. This makes it a great choice for working in difficult spaces at remote locations.
The spreader in the SWi1214TMSTDEX set fits into very small clearance gaps of 0.24 inch (6 mm).
Features
Set Includes
- 1 x SWi12/14TM Mechanical Flange Spreader Wedgehead
- 1 x 12/14TM Mechanical Cylinder
- 1 x Torque Wrench with 22 mm Socket
- 1 x Set of Safety Blocks
- 1 x Pair of Stepped Blocks
- 1 x Safety Lanyard
- 1 x Hex Key
- Case dimensions (in) 22.8 x 15.7 x 7.1
User Features
- Practical, portable, and lightweight
- Molded plastic handle for comfort
- Revolving handle to aid horizontal or vertical spreading
- Removable handle for improved access
Safety Features
- No finger pinch-points
- Increased step depth on upper steps
- Safety lanyard - 1.0 m (39") length
- Forged key components for strength and reliability
Maintenance Features
- Rapid disassembly and assembly
- Narrow jaw teeth - improved tool wear
Units:
Case Dimensions (in)22.8 x 13.0 x 6.5
Spreader Set TypeStandard Set
Maximum Operating Torque (Nm)175
Weight (kg)13
Case Dimensions (mm)580 x 330 x 165
Model TypeSingle Wedge Set
Maximum Operating Torque (Ft.lbs)130
rentalPrice63
Maximum Spread (in)4.1
Power SourceMechanical
Jaw Width (in)2.36
Weight (lbs)28.7
Capacity (Imperial tons)15.7
Jaw Width (mm)60,0
Product TypeFlange Spreader Set - Wedges
Certification StatusNot Atex certified
Capacity (kn)140
Tip Clearance (mm)6
Capacity (Metric Tons)14
Tip Clearance (in)0.24
Maximum Spread (mm)103.5
