SWi2025TESTDSPB, 26.9 Ton, External Hydraulic Flange Spreader Standard Set, 4.1 in Maximum Spread
Item ID: SWI2025TESTDSPB
$6,129.65
Free ShippingEst. Ship date is Tue, JunĀ 22nd 2027
Product Description
This standard Equalizer set includes a flange spreader, hydraulic cylinder, sealed hydraulic hand pump with gauge, safety block and lanyard - all are supplied within the robust carry case.
The hydraulic spreader used with the supplied hand pump makes it easy to exert a powerful force for separating flanges.
Product Specifications
Model TypeSingle Wedge and Pump Set
Power SourceExternal Hydraulic
Maximum Spread (in)4.1
Available - Backorder
About this Product
This standard Equalizer set includes a flange spreader, hydraulic cylinder, sealed hydraulic hand pump with gauge, safety block and lanyard - all are supplied within the robust carry case.
The hydraulic spreader used with the supplied hand pump makes it easy to exert a powerful force for separating flanges.
Features
Standard Set Includes
- 1 x SWi20/25TE Flange Spreader Wedgehead
- 1 x 10,000 psi Hydraulic Cylinder
- 1 x Safety Block
- 1 x Lanyard
- 1 x 1 x 10,000 psi (700 bar) Hydraulic Hose, 78.8" (2 m) with 90 degree elbow
- 1 x 10,000 psi (700 bar) HP350S Single-Port Sealed Hand Pump with Gauge
- Case dimensions (in) 26.8 x 22 x 7.1
- Practical, portable and lightweight
- Molded plastic handle for comfort
- Revolving handle to aid horizontal or vertical spreading
- Removable handle for improved access
- No finger pinch-points
- Increased step depth on upper steps
- Safety lanyard - 39 inches (1 m) length
- Forged key components for strength and reliability
- Rapid disassembly and assembly
- Narrow jaw teeth - improved tool wear
Units:
Model TypeSingle Wedge and Pump Set
Power SourceExternal Hydraulic
Maximum Spread (in)4.1
Tip Clearance (in)0.24
Case Dimensions (in)36.2 x 19.7 x 8.1
Case Dimensions (mm)920 x 500 x 205
Certification StatusNot Atex certified
Jaw Width (in)2.36
Jaw Width (mm)60,0
Maximum Spread (mm)103.5
Spreader Set TypeStandard Set
Tip Clearance (mm)6
Maximum Operating Pressure (bar)700
Maximum Operating Pressure (psi)10000
Capacity (Imperial tons)27
Capacity (kn)240
Capacity (Metric Tons)24
Weight (lbs)45.6
Weight (kg)20.7
Product TypeFlange Spreader Set - Wedges
