WR5, 1.00 Ton, Hydraulic Wedgie and Spread Cylinder, 3.7 in Maximum Spread
Item ID: WR5
$610.79
Free ShippingEst. Ship date is Wed, Oct 28th 2026
Product Description
When you need a compact hydraulic wedge spreader for tight spaces the WR5 is the optimum choice. This single-acting tool uses powerful hydraulic force to expand up to 3.7" (94mm) and retracts with a spring return system.
Please note that the maximum load capacity is 1-ton (8.9kN), and the maximum system pressure must be limited to half the rated pressure (5000 psi 350 bar).
Product Specifications
Spreading Force (imperial tons)1
Maximum Spreading Force (kN)8,9
Weight (lbs)5
Available - Backorder
About this Product
When you need a compact hydraulic wedge spreader for tight spaces the WR5 is the optimum choice. This single-acting tool uses powerful hydraulic force to expand up to 3.7" (94mm) and retracts with a spring return system.
Please note that the maximum load capacity is 1-ton (8.9kN), and the maximum system pressure must be limited to half the rated pressure (5000 psi 350 bar).
Units:
Spreading Force (imperial tons)1
Maximum Spreading Force (kN)8,9
Weight (lbs)5
Tip Clearance (in)0.5
Weight (kg)2,3
Maximum Operating Pressure (bar)700
Tip Clearance (mm)12,8
Maximum Operating Pressure (psi)10000
Maximum Spread (in)3.7
Maximum Spread (mm)94
Power SourceHydraulic
Compatible ProductsRC5,RC10
Cylinder Effective Area (cm2)6,5
Stroke (mm)8.9
Capacity (Imperial tons)1
Maximum Spreading Force (ton)1
Product TypeHydraulic Spreader
